RENDER GALLERY / Enables access to multiple versions of renderings, render images as panoramas, change rendering quality, and apply background environments to rendered scenes. RENDER IN CLOUD / Renders 3D views online. ISOLATE CATEGORY / Isolates selected categories. RESET TEMPORARY HIDE/ISOLATE / Restores any temporarily hidden elements or categories. HIDDEN LINE / Displays the image with all edges and lines drawn except those obstructed by surfaces. ISOLATE ELEMENT / Isolates selected elements. HIDE ELEMENT / Hides an element from view. HIDE CATEGORY / Hides all selected categories in the view. GRAPHIC DISPLAY OPTIONS / Opens the Graphics dialog box. TOGGLE REVEAL CONSTRAINTS MODE / Toggles the constraints in a view.
PLUMBING FIXTURE / Places a plumbing fixture.ĬABLE TRAY FITTING / Places cable tray fittings. PIPE FITTING / Draws a pipe fitting in a piping system. MECHANICAL EQUIPMENT / Places mechanical equipment such as boilers, furnaces or fans.ĬONDUIT FITTING / Places conduit fittings. LIGHTING FIXTURE / Adds a lighting fixture element. HIDE IN VIEW:HIDE CATEGORY / Hides an element category from view.ĪIR TERMINAL / Places a register, grille or diffuser.ĬONVERT TO FLEX DUCT / Converts a section of rigid duct to flexible duct.ĭUCT ACCESSORY / Adds duct accessories, such as dampers, in duct systems.ĭUCT FITTING / Places duct fittings (elbows, tees, end caps, and so on) in duct systems.ĭUCT / Draws ductwork in the building model.ĮLECTRICAL EQUIPMENT / Places electrical equipment, such as panels and switch gear.įLEX DUCT / Draws flexible ductwork in the building model. UNPIN / Unpins an element that is locked in position or an element that is driven by its host system. TRIM/EXTEND TO CORNER / Trims or extend one or more elements to form a corner. SPLIT ELEMENT / Cuts an element (such as a wall or line) at a selected point. SPLIT FACE / Divides the face of an element into regions for application of different materials. ROTATE / Rotates selected element around an axis. OFFSET / Moves a selected model line, detail line, wall, or beam a specified distance perpendicular to its length. MIRROR - PICK AXIS / Reverses the position of a selected model element, using a selected line as the mirror axis. MATCH TYPE PROPERTIES / Opens the Match Type tool to convert one or more elements to match the type assigned to another element. LINEWORK / Overrides the line style of selected line in the active view only. OVERRIDE GRAPHICS IN VIEW:OVERRIDE BY ELEMENT / Changes the graphic display settings for selected elements in the current view. HIDE IN VIEW:HIDE ELEMENTS / Hides an element from view. MIRROR - DRAW AXIS / Reverses the position of a selected model element, using a user-generated line as the mirror axis. UNHIDE CATEGORY / Enables a hidden category to appear in view.ĪLIGN / Aligns one or more elements with selected element.ĪRRAY / Creates a linear or radial array of selected elements.ĬOPE APPLY COPING / Applies coping to steel beam or columns.ĬREATE SIMILAR / Creates an element of the same type as the selected element.ĭELETE / Removes selected element(s) from the building model. REFERENCE PLANE / Creates a reference plane using drawing tools. TOGGLE REVEAL HIDDEN ELEMENTS MODE / Toggles the Reveal Hidden Elements Mode. REMOVE FROM GROUP / Removes elements from a group. RESTORE ALL EXCLUDED / Restores all excluded parts and elements. PROPERTIES TOGGLE PROPERTIES PALETTE / Toggles the Properties palette. MODEL LINE BOUNDARY LINE REBAR LINE / Places a new line. ZOFFSET / Offsets an element in the z direction. JUSTIFICATION POINTS / Sets a justification point for relocating elements. SHOW HELP TOOLTIP / Displays the Help Tooltip. UNHIDE ELEMENT / Enables a hidden element to appear in view.ĮDIT WITNESS LINES / Edits a witness line. SPOT ELEVATION / Displays the elevation of a selected point.
Autodesk graphic display options series#
STRUCTURAL BEAM SYSTEM AUTOMATIC BEAM SYSTEM / Creates a layout that is used to control the number and spacing of a series of parallel beams.ĪLIGNED DIMENSION / Creates an aligned dimension.
